Technical Specifications

• Power Source: Standard gas cylinder (1.6 kg/5lbs capacity) or STD compressed air line
• Performance Approx 300 injections/hour.
• Mode of Injection Intradermal: Subcutaneous or Intra-muscular
• Reservoir Standard: Standard luer-lock 5 cc up to 10 cc sterile plastic syringe
• Type of Injection: Injectables up to 120cp
• Vaccine Quantity: Fixed volume of 0.02; 0.03; 0.05 & 0.1 cc
• Accuracy: Plus/minus 1% at 0.5cc cc
• Material: Stainless steel; Aluminum and plastic
• Sterilization: Autoclave
• Weight of Injector: Approx. 0.24 kg (0.52 lbs)
• Weight of Cylinder: Approx. 5 kg to 10 kg (11 to 22 lbs)
• Applications: Local Anesthesia, General Routine Procedures, Clinical Dermatology, Cosmetic & Plastic Surgery
